R88G-HPG20A45200B OMRON Industrial Pattern Single Phase AC Motor

Product Categories
LINTURE  Technology CO.,LTD
Contact Now

R88G-HPG20A45200B OMRON Industrial Pattern Single Phase AC Motor

  • 1
  • 2

Brand Name : OMRON

Model Number : R88G-HPG20A45200B

Certification : CE

Place of Origin : China

MOQ : 1 pc

Price : negotiable

Payment Terms : T/T, , L/C

Supply Ability : 88

Delivery Time : 5-8DAYS

Packaging Details : New in original box

Warranty : 12 Months

Condition : New and original

Quality : New and Original

Type : Single phase ac motor

Contact Now

Brand: OMRON Model: R88G-HPG20A45200B
Origin: China
High Light:

ewing machine servo motor

,

ac servo motor

OMRON R88G-HPG20A45200B Decelerator For 200W Cylindrical Servomotors Backlash Within 3 Minutes Deceleration Ratio 1/45

Backlash: 3 Arcminutes Max.

Decelerators for 3,000-r/min Servomotors

Model
(R88G-)		 Rated
ro-
tation
speed		 Rated
torque		 Effi-
cien-
cy		 Maxi-
mum
mo-
mentary
rotation
speed		 Maxi-
mum
mo-
men-
tary
torque		 De-
celerator
inertia		 Al-
low-
able
radial
load		 Al-
low-
able
thrust
load		 Weight
r/min N·m % r/min N·m kg·m2 N N kg
50
W		 1/5 HPG11B05100B 600 0.50 63 1000 1.42 5.00 × 10-7 135 538 0.29
1/9 HPG11B09050B 333 1.12 78 555 3.16 3.00 × 10-7 161 642 0.29
1/21 HPG14A21100B 143 2.18 65 238 6.13 5.00 × 10-6 340 1358 1.04
1/33 HPG14A33050B 91 3.73 71 151 10.5 4.40 × 10-6 389 1555 1.04
1/45 HPG14A45050B 67 5.09 71 111 14.3 4.40 × 10-6 427 1707 1.04
100
W		 1/5 HPG11B05100B 600 1.28 80 1000 3.6 5.00 × 10-7 135 538 0.29
1/11 HPG14A11100B 273 2.63 75 454 7.39 6.00 × 10-6 280 1119 1.04
1/21 HPG14A21100B 143 5.40 80 238 15.2 5.00 × 10-6 340 1358 1.04
1/33 HPG20A33100B 91 6.91 65 151 19.4 6.50 × 10-5 916 3226 2.4
1/45 HPG20A45100B 67 9.42 65 111 26.5 6.50 × 10-5 1006 3541 2.4
200
W		 1/5 HPG14A05200B 600 2.49 78 1000 6.93 2.07 × 10-5 221 883 1.02
1/11 HPG14A11200B 273 6.01 85 454 16.7 1.93 × 10-5 280 1119 1.09
1/21 HPG20A21200B 143 10.2 76 238 28.5 4.90 × 10-5 800 2817 2.9
1/33 HPG20A33200B 91 17.0 81 151 47.4 4.50 × 10-5 916 3226 2.9
1/45 HPG20A45200B 67 23.2 81 111 64.6 4.50 × 10-5 1006 3541 2.9
400
W		 1/5 HPG14A05400B 600 5.66 87 1000 16.0
(15.7)		 2.07 × 10-5 221 883 1.09
1/11 HPG20A11400B 273 11.7 82 454 33.1
(32.5)		 5.70 × 10-5 659 2320 2.9
1/21 HPG20A21400B 143 23.5 86 238 66.5
(65.2)		 4.90 × 10-5 800 2547 2.9
1/33 HPG32A33400B 91 34.7 81 151 98.2
(96.3)		 6.20 × 10-5 1565 6240 7.5
1/45 HPG32A45400B 67 47.4 81 111 133.9
(131.4)		 6.10 × 10-5 1718 6848 7.5
750
W		 1/5 HPG20A05750B 600 9.94 83 1000 29.2 6.80 × 10-5 520 1832 2.9
1/11 HPG20A11750B 273 23.2 88 454 68.1 6.00 × 10-5 659 2320 3.1
1/21 HPG32A21750B 143 42.3 84 238 124.3 3.00 × 10-4 1367 5448 7.8
1/33 HPG32A33750B 91 69.7 88 151 204.7 2.70 × 10-4 1565 6240 7.8
1/45 HPG32A45750B 67 95.0 88 111 279.2 2.70 × 10-4 1718 6848 7.8
1
kW		 1/5 HPG32A051K0B 600 11.5 72 1000 32.9 3.90 × 10-4 889 3542 7.3
1/11 HPG32A111K0B 273 28.9 83 454 82.6 3.40 × 10-4 1126 4488 7.8
1/21 HPG32A211K0B 143 58.1 87 238 166.1 3.00 × 10-4 1367 5488 7.8
1/33 HPG32A331K0B 91 94.3 90 151 270.0 2.80 × 10-4 1565 6240 7.8
1/45 HPG50A451K0B 67 124.2 87 100 *1 355.4 4.70 × 10-4 4538 15694 19.0
1.5
kW		 1/5 HPG32A052K0B 600 19.1 80 1000 51.3 3.90 × 10-4 889 3542 7.4
1/11 HPG32A112K0B 273 45.7 87 454 122.5 3.40 × 10-4 1126 4488 7.9
1/21 HPG32A211K5B 143 90.1 90 238 241.9 3.00 × 10-4 1367 5448 7.9
1/33 HPG50A332K0B 91 141.5 90 136 *1 379.7 4.80 × 10-4 4135 14300 19.0
1/45 HPG50A451K5B 67 192.9 90 100 *1 517.8 4.70 × 10-4 4538 15694 19.0
2
kW		 1/5 HPG32A052K0B 600 26.7 84 1000 77.4 3.90 × 10-4 889 3542 7.4
1/11 HPG32A112K0B 273 62.4 89 454 180.7 3.40 × 10-4 1126 4488 7.9
1/21 HPG50A212K0B 143 118.9 89 214 *1 343.9 5.80 × 10-4 3611 12486 19.0
1/33 HPG50A332K0B 91 191.8 91 136 *1 555.0 4.80 × 10-4 4135 14300 19.0
3
kW		 1/5 HPG32A053K0B 600 42.0 88 1000 118.9 3.80 × 10-4 889 3542 7.3
1/11 HPG50A113K0B 273 92.3 88 409 *1 261.4 7.70 × 10-4 2974 10285 19.0
1/21 HPG50A213K0B 143 183.0 91 214 *1 517.7 5.80 × 10-4 3611 12486 19.0
4
kW		 1/5 HPG32A054K0B 600 53.9 90 900 *1 163.4 3.80 × 10-4 889 3542 7.9
1/11 HPG50A115K0B 273 124.6 90 409 *1 359.0 8.80 × 10-4 2974 10285 19.1
5
kW		 1/5 HPG50A055K0B 600 69.3 88 900 *1 197.8 1.20 × 10-3 2347 8118 17.7
1/11 HPG50A115K0B 273 158.4 91 409 *1 451.9 8.80 × 10-4 2974 10285 19.1

Note: 1. The values inside parentheses ( ) are for 100-V Servomotors.
Note: 2. The Decelerator inertia is the Servomotor shaft conversion value.
Note: 3. The protective structure for Servomotors with Decelerators satisfies IP44.
Note: 4. The allowable radial load is the value at the T/2 position.
Note: 5. The standard models have a straight shaft. Models with a key and tap are indicated by adding "J" to the end of
the model number (the suffix in the box).

Decelerators for 3,000-r/min Cylindrical Servomotors
Straight shaft

Specifications Model
Motor capacity Gear ratio
50 W 1/5 R88G-HPG11B05100B
1/9 R88G-HPG11B09050B
1/21 R88G-HPG14A21100B
1/33 R88G-HPG14A33050B
1/45 R88G-HPG14A45050B
100 W 1/5 R88G-HPG11B05100B
1/11 R88G-HPG14A11100B
1/21 R88G-HPG14A21100B
1/33 R88G-HPG20A33100B
1/45 R88G-HPG20A45100B
200 W 1/5 R88G-HPG14A05200B
1/11 R88G-HPG14A11200B
1/21 R88G-HPG20A21200B
1/33 R88G-HPG20A33200B
1/45 R88G-HPG20A45200B
400 W 1/5 R88G-HPG14A05400B
1/11 R88G-HPG20A11400B
1/21 R88G-HPG20A21400B
1/33 R88G-HPG32A33400B
1/45 R88G-HPG32A45400B
750 W 1/5 R88G-HPG20A05750B
1/11 R88G-HPG20A11750B
1/21 R88G-HPG32A21750B
1/33 R88G-HPG32A33750B
1/45 R88G-HPG32A45750B
1 kW 1/5 R88G-HPG32A051K0B
1/11 R88G-HPG32A111K0B
1/21 R88G-HPG32A211K0B
1/33 R88G-HPG32A331K0B
1/45 R88G-HPG50A451K0B
1.5 kW 1/5 R88G-HPG32A052K0B
1/11 R88G-HPG32A112K0B
1/21 R88G-HPG32A211K5B
1/33 R88G-HPG50A332K0B
1/45 R88G-HPG50A451K5B
2 kW 1/5 R88G-HPG32A052K0B
1/11 R88G-HPG32A112K0B
1/21 R88G-HPG50A212K0B
1/33 R88G-HPG50A332K0B
3 kW 1/5 R88G-HPG32A053K0B
1/11 R88G-HPG50A113K0B
1/21 R88G-HPG50A213K0B
4 kW 1/5 R88G-HPG32A054K0B
1/11 R88G-HPG50A115K0B
5 kW 1/5 R88G-HPG50A055K0B
1/11 R88G-HPG50A115K0B
